Gigabit L2+ Managed PoE Switch
28-port Gigabit L2+ managed PoE switch with 24 PoE ports, 4 Gigabit SFP uplinks, 400W PoE power budget, IPv6 support, advanced security, VLAN management, and enterprise-grade network performance.
HVP2804M6
The HVP2804M6 Gigabit L2+ Managed PoE Switch is a high-performance enterprise networking solution designed for IP surveillance systems, enterprise LAN infrastructure, smart buildings, data communication networks, industrial networking, and professional PoE deployments. Featuring advanced Layer 2+ management capabilities, Gigabit data transmission, and intelligent security functions, the switch delivers reliable, scalable, and secure network connectivity for modern business environments. The switch is equipped with 24 Gigabit PoE RJ45 ports, 4 Gigabit SFP fiber uplink ports, and 1 console management port, providing flexible connectivity for IP cameras, wireless access points, VoIP phones, smart access systems, servers, and enterprise network devices. Supporting IEEE 802.3af/at PoE standards with a total 400W PoE power budget, the HVP2804M6 enables centralized power and data transmission through a single Ethernet cable. Designed for demanding enterprise applications, the switch offers a powerful 56Gbps switching capacity, 41.664Mpps packet forwarding rate, and support for 10K jumbo frames, ensuring smooth high-bandwidth network performance for HD video surveillance, cloud services, and data-intensive applications. The HVP2804M6 supports advanced networking features including Static IPv4/IPv6 routing, STP/RSTP/MSTP spanning tree protocols, IEEE 802.1Q VLAN, QinQ, Link Aggregation (LACP), QoS traffic management, multicast control, ACL access management, and comprehensive Layer 2/3/4 security policies. For enhanced network security and management, the switch integrates advanced protection technologies such as AAA authentication, TACACS+, RADIUS, IEEE 802.1X, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, IMPB, Storm Control, DoS Prevention, CPU Defense Engine, SSL/TLS encryption, and SSH secure management. The device also supports comprehensive IPv6 networking and intelligent management features including SNMP v1/v2c/v3, HTTPS WebUI, CLI management, LLDP/LLDP-MED discovery, RMON monitoring, Syslog diagnostics, port mirroring, Ping test, and Traceroute troubleshooting. Built with enterprise-grade reliability and advanced management functionality, the HVP2804M6 is an ideal solution for scalable and secure Gigabit PoE network infrastructures.
